Create Folder Activity

Created by akaBot Support, Modified on Wed, 26 Mar at 10:02 AM by akaBot Support

Activity Program Name
Description
Properties
How to Use

1. Activity Program Name

RCA.Activities.Core.CreateDirectory

2. Description

For Studio versions up to 2.0.2.0:

Quick Access: "Toolbox" > "Core" > "Create Folder"

For Studio versions from 2.0.3.0 onwards:
Quick Access: "Toolbox" > "Core" > "File" > "Create Folder"

This activity creates a folder at a specified location.

※ Verified akaBot Studio version: 2.0.1.3

※ Note: Terminology or wording may vary slightly depending on the version.

3. Properties

Property Group	Property Name	Input Field	Description
Misc	Public	Checklist	The variables and arguments within the activity are written to the log file and pushed to the Center. (See: "Property Item: Public.")
Misc	Display Name	Input value (String)	Reflected in the Designer Panel as the activity's name.
General	Continue on error	Input value (Boolean)	Proceed to subsequent processing on error.
Output	Target Path	Input value (String)	Create Folder Path

4. How to Use

Below is a real example of using the "Create Folder" activity:

Create "C:\akaBotStudio\TestFolder".

In akaBot Studio, drag and drop the ① "Create Folder" activity into the designated sequence. Once the activity is added, specify the path of the folder to be created.

Below is an example screenshot.

To implement the example above:

② In Properties > Folder > Path, enter "C:\akaBotStudio\TestFolder".

With these entries, the configuration for Create Folder is complete.
